Ibanez BN5 Black Noise
An old request. This is pretty much a Rat with an active treble control and two fixed eq gyrators making it quite bass heavy. Lots of mods can be done like a diode switch, tweaking the gyrators and the tonestack as well as tweaking the RC filter at the first gainstage.
Ibanez EM5 Echomachine Delay
Factory schematic is avaiable HERE. Deadend Fx has a good trimpot setup guide HERE.
Ibanez LA Metal LM7
A quite interesting Rat derivate which is also found the “LA” mode in the newly released PackRat pedal from JHS. Schematic is avaiable HERE.
Ibanez No. 95 Renometer
This was a request. Appearantly a very powerful booster and eq circuit using inductors for sort of multiband wah sounds. The original ran on two 9v batteries for bipolar power operation but I included an onboard power inverter. Note that sizes of inductors varies a lot but hopefully there is enough room for them, especially … Read more
Fuzz Machine: Unbranded Ibanez Standard Fuzz
The Fuzz Machine is clearly an unbranded Ibanez No 59 Standard Fuzz. I occasionally buy a few parts from a retired guy with a shed full of vintage electronics and components, mostly valves and radio gear. A while back, he mentioned that there were a couple of pedals buried somewhere in the shed. I was … Read more
IBANEZ: Overdrive OD-850
The Ibanez Overdrive OD-850 is an early Japanese Big Muff variation, almost a straight clone if it wasn’t for the usual tone stack. It’s also known as the Maxon D&S OD-801 – either way, both classic guitar effects from Japan. The tone stack fixes the bass response to some degree, providing a more even sweep across the range. … Read more
Ibanez No. 58 Standard Wau Fuzz – Fuzz section
Similar to the Ibanez No 59 Standard Fuzz but with a different tone section and a few extra resistors. If you want a bit more overall output level, 47k resistor connecting to Balance 3 could be can be replaced with a small value or a jumper. Another useful mod is to sub the germanium diodes … Read more
