Black Arts Toneworks Witch Burner
Black Arts take on the Tubescreamer…traced by evilarsen. Once again, thanks! This one is verified.
Month: January 2021
INTERFAX: Harmonic Percolator, Point to Point Layout
I would recommend breadboarding this prior to committing to solder. The Interfax Harmonic Percolator is very tweakable, and sometimes takes some adjusting to get it right. There’s pages on the Harmonic Percolator on DIY Stompboxes. INTERFAX HARMONIC PERCOLATOR – POINT TO POINT LAYOUT
Fairfield Circuitry Barbershop Millenium (maybe…)
Per request. Note that the values for the treble cut capacitors is nor confirmed (10nF and 22nF) so it might be worth socketing these values. Also, I replaced the Drain resistors with trimpots for easier biasing for the J FETs.
Mellowtone Wizard Fountain
An obscure little fuzz circuit from yesteryear with a neat litlle “Twist” control and Nocentellis gain control mod. Schematic is avaiable HERE.
DALLAS: Rangemaster, Tag Board Layout
A bit of a classic – well one of the first guitar effects really, the Dallas Rangemaster. A nice simple one for a quick build using leftover tag board. In theory there is room to fit the output cap on the board too, but I liked the straight lines of the components. DALLAS RANGEMASTER TREBLE … Read more
