It’s been a while – and I’ve probably scared most of you away with obscure amp content, but I have to have a crack at this one. Yes, it could have been a smaller layout, but to be honest, I’d still be adding some room around the edges for proper mounting points. I also … Read more
Schematic is avaiable HERE. Two thumbs up to Lacesensor at Gigahearts Fx for doing most of the footwork for the trace.
Per request. Was a bit hesistant to upload this since there are three missing cap values. But socketing some values should get you close enough. magus femar did some socketing and ended up with some values that works well. See the notes below the layout. Note that I omitted the ferrite beads since they are … Read more
A vintage big box The Worm with some useful improvemnts and mods by Madbean. The power section have been reworked by a voltage doubler and a voltage regulator for 9v to 15v operation. An internal volume trimpot is added. And the unknown original vactrols is replaced by a trio of LDR/LED pair. Schematic and more … Read more
Layout based on the old version from the 70s. Note that this one is really picky about op amp selection so be prepared for some socketing…
Uh oh, everything Josh does at the moment seem to hit the fan… *update 230421* The cap avalues and transistors is now figured out for both the big box version and Nano version. An additional layout for the Nano version is uploaded. Big box version Nano version Demo by Mr … Read more
So just out, and with all of the suitable hype and controversy expected – the EHX / JHS Lizard Queen. Trace and discussion in progress on FSB – it looks relatively similar to some old DIY designs out there, which is the cause of much of the controversy. Well, not so much what they are based … Read more
A nice easy one – the Electro-Harmonix Muff Fuzz, which has a lot more in common with a Fuzz Face than a Big Muff. At some stage I’ll add some more layouts, including the Mark Hammer mods and the IC version. ELECTRO-HARMONIX MUFF FUZZ – VERO LAYOUT
Found this in an older folthe usuader that I forgot. Includes some necesarry modernazations like true bypass, onbard charge pump, input and output caps and pulldown resistors. Schematics is avaiable HERE.
