EarthQuaker Devices
Earthquaker Devices Disaster Transport
I traced this one a while back. It’s the same delay circuit as the Disaster Transport Jr but with modulation added. It fits nicely in a 1590BB like the original. Schematic here. If you’d rather a smaller footprint I have fabricated boards for a 125B in the store.
EarthQuaker Devices Rainbow Machine
Chris “SPIN Doctor” Stelloh did it again! Amazing work with this box of fairy dust and chaos. The layout is verified and good to go! …and here is a layout with “Stelloh mods“.
EQD Fuzz Master General
Happy Fuzz Friday! Here’s a Univox Super Fuzz derived circuit from Earthquaker. Should squeeze into a 1590B just fine. Here’s the schematic for reference:
EarthQuaker Devices Organizer
Chris just sent me an another Spin FV-1 based layout. And he verified it. “This is a layout for the Earthquaker Organizer Polyphonic Organ Emulator that I drew up using the Pedalpcb schematic. Two things about this layout (which is verified – I have all ready built it): 1) it addresses the volume drop issue … Read more
EarthQuaker Devices Dream Crusher
Traced by Unsound Circuitry, once again, thanks, mate! It is a well known fact that this is a modified Ge Fuzz Face. The stock Fuzz control is ditched and replaced with a “Pre Gain2 control. It runs on normal power supply and is powered by soviet MP37B NPN germanium transistors. These are usually faily low … Read more
