Still on the Vox thing at the moment – just a little Distortion Booster using a variation on the Colorsound fuzz box layout. It’s the red box version, here’s the thread on FSB with the schematic etc. Like so many vintage effects, there seems to be a few versions of the circuit. VOX DISTORTION BOOSTER … Read more
This is a nice simple one, and a slight variation on the Colorsound Fuzz Boxes that I’ve been building lately. Basically a silicon fuzz face variant, which is a progression from their original booster that just had an on/off switch. VOX DISTORTION BOOSTER | 0.15″ VERO LAYOUT And if you’re wondering what’s going on with … Read more
Chuck D. Bones take on one of Björn Juhl’s designs, a hot rodded Honey Bee. Lots of tweaks all over the place so it probably differ quite a bit compared to the original circuit. I subbed the hard to source clipping diodes for NPN transistors to match the voltage drop and knee. Regular 1N4148s will … Read more
Another very interesing by Chuck D. Bones over at the PedalPCB forum. The inspiration comes from some of Catalinbreads overdrive and fuzz designs but adds a lot of refinement amd tweakability.. Schematic is avaiable HERE.
Nils from Moonn Electronics took a stab on the Big Muff and twisted the knife… Looks pretty cool. MOSFET and regular silicon transistors, blue LED clippers and a wild tonestack. Schematic and BOM can be found HERE.
Foxx sold a couple of wah variants in the early 70s, often combined with a Foxx Tone Machine circuit. There was an inductorless version and a Cry Baby variant with a 4 posistion “Wah Tone” selector switch. This layout is for the inductorless version. HERE is the schematic.
Now this is mainly for my own purposes, as I doubt anyone else will want to build a Rat this way & I only plan on making one. Just a standard Rat, built on 0.15″ vero and I’ve prioritised looks of build practicality (or at least what I think looks good anyway). I have built … Read more
