Request for Phil – one tag board layout for the Park 2 knob fuzz sound. I generally prefer to keep the links below the board, as it looks neater. I don’t mind linking two adjacent lugs on top, as you hardly notice it.
One suggestion for this. The D*A*M Colosround Fuzz Sound has a few different values and an internal trimmer to fine-tune the fuzz. They say that it’s set at about 90% – so given that the pot is normally 100k, you could use a 10k resistor instead of a link under the board, or any value resistor of your choice.
Check the MKIII component values table as a reference. Stock values are listed below.
PARK TWO KNOB FUZZ – TAGBOARD LAYOUT
