Booster
Hornby Skewes Shatterbox
Slightly modernized and improved. The original ran on negative power supply with low gain jellybean PNP silicon transistors with BCE pinout. This layout calls for low gain NPN silicon transistors with CBE pinots so you can easily socket the normal suspects like PN2222, 2N3903 etc. And a trimpot for the biasing the fuzz section replaces … Read more
Funny Little Boxes Skeleton Key
This is supposed to be a QOTSA in a box. According to demos online, this and an amp on the verge of breakup will almost get you there… The 470uF power filter cap is a bit overkill, you can use a 100uF instead. Schematic is avaiable HERE.
1981 Inventions LVL
Schematic is avaiable HERE. Original buffered bypass version …and a requested true bypass version.
