BYOC
BYOC Parametric EQ
Another “requested” monster layout! At least this one doesn’t use any weird components. You can find all infos and schematic from their website here.
BYOC Crown Jewel
Here is a layout for the BYOC Crown Jewel (minus the boost). The boost is an independent circuit of your choice in serie with the main circuit. There is also an extra switch to select if you want the boost “Pre” or “Post” the main circuit. You can find all infos and schematic on their … Read more
BYOC Confidence Booster
The BYOC Confidence Booster is just a simple linear boost and buffer. The only change i made was moving the trimmer offboard to make a pot. Figured this would be a nice easy project for those that want to get started building pedals.
BYOC 27V Boost
Taken directly from BYOC. Possibly the World’s cleanest, most transparent boost. It utilizes the 7660S charge pump’s ability to take a standard 9v power supply and output both +18v and -9v. The op-amp based boost circuit takes advantage of the whopping 27v differential to produce 20dB with an amazing amount of headroom. It doesn’t matter … Read more
BYOC Reverb 2
Got a request to make a layout for this schematic, and it turns out it’s the BYOC Reverb 2. You can use 9mm pots and board mount them from the component side if you like. There are a few jumpers, though one of them (the one by the lower IC) can be eliminated if you … Read more
Klon Centaur Silver Edition
Keith at BYOC reverse engineered a silver edition Klon when developing a PCB and noticed an error on soulsonic’s 2009 schematic which was a couple of swapped resistor values around the Treble pot. He also noticed a few value discrepancies which probably just amount to the difference between the gold and silver Klons. The swapped … Read more
BYOC Tremolo
Request. The stomp is wired in an unusual way so I have shown exactly how to do it. The reason for this is that during bypass the input to the effect is grounded and the emitter of the LFO transistor is disconnected from ground, and so stops the LFO continuing to cycle during bypass. This … Read more
