It s time for a guest appearance! Chris Stelloh of Capitalist Death Cult requested a layout for this one a while ago but I couldn’t do it at the time so he went off and did his own. The layout is verified and good to go. It is basically a EHX Bassbals with quite a … Read more
The last layout for a while, I honesly don’t know when the next one will be uploaded, probably in january. There is three eye surgeries on the horizon… Anyway, I had athe change to trace an old EHX Muff Fuzz of the op amp variety a few weeks ago. As you know, EHX used parts … Read more
The blog needs more modulation, so here’s the classic EHX Small Clone chorus. Made famous by Kurt Cobain, the Small Clone has a wide range of chorus tones. I’ve laid it out two ways, one stock, and one with the Depth switch replaced with a pot. You can probably squeeze this into a 1590B, but … Read more
The late EH3054C version of the vintage Deluxe Big Muff. Some improvements had to be done like true bypass and common voltage refrence. Schematic is avaiable HERE.
This is a monster! It is based on the schematic by Lectric Fx which includes a recovery stage with internal trimpots to set the output volume.Schematic is avaiable HERE.
This is it for, now. Covid restrictions were lifted here today so I’m going to take a break and try to live a normal life for a while ;-). But here is a project of the 70s version of EHX Clone Theory which should keep you occupied for a while. An onboard voltage doubler is … Read more
Ok, another monster of a layout… Here is a delay based on the earliest version of EHX Memory Man (not Deluxe version). The obsolete and super rare SAD1024 BBDs is replaced by a PT2399 and is supposed to share almost the same sonic qualities, i.e. dark and murky. The rest of the audio circuit is … Read more
Here we have a rare bird from the early-mid 70s. A tweaked version of the the circuit found in Freedam Preamp amp found its way into some Big Muff enclosures. Original is very pricey and rare. The original ran on two 9v batteries for bipolar power supply for the op amp section but I added … Read more
