EWS
EWS FD-1 Fuzzy Drive
Based on Seamoon Fuzz (…and Black Cat OD-1). An op amp clipping fuzzy overdrive with an active tonec ontrol tacked at the end. Note that the schematic have a few typos; the 470nF caps is actually 47nF according to some gutshots but 470nF might work for the bass players out there…
EWS Tri-Logic Bass Preamp II
Here’s a pretty simple but effective bass preamp from EWS. It’s a 3-band EQ being pushed by a MOSFET gain stage. Looks like EWS made a version for Xotic with the same name. Not a lot different between the two other than some value changes laid out in this schematic on FSB. I’ve laid it … Read more
EWS Little Brute Drive
From the source: Following the very well received Brute Drive, we are proud to introduce the newest pedal from EWS, the Little Brute Drive (LBD). From its small body, jumps out an intense distortion similar to its big brother, the Brute Drive. Its compact design takes us very little real estate. It will fit anywhere … Read more
EWS Little Brute Drive
Found this one on FSB and haven’t seen any layouts for it, so I thought I’d give it a go. Originals are in 1590A enclosures with the Tone and Volume controls as trimmers, but I’ve laid them out as external controls. There seems to be some discrepancy on the taper of the gain control in … Read more
EWS Bass Mids Control
Here’s another one for the bass players. It’s a pretty handy EQ pedal from EWS. Originals come in a 1590a, and sadly I wasn’t able to duplicate that here, but it will fit fine in a 1590B with board mounted pots. Originals have the Volume control as an internal trimmer, but I’ve moved that to … Read more
