Fuzzlord Effects Troglodyte
A recovery stage is needed because of the lossy tonestack Here is an another layout with an added BJT boost stage.
Fuzzlord Effects
Fuzzlord Effects Riff Master
Another trace by evilarsen. This is basically a Rangemaster tuned for more low end..
Fuzzlord Effects FET 120 Overdrive – transistor version
Another one traced by evilarsen. A J FET preamp emulator loosely based on Orange OR120. This one is already verified.
Fuzzlord Effects Drone Master
Here is another trace by evilarsen; Fuzzlord Drone Master. It is essentially a tweaked Rat with a diode selector switch, a switchable twin T notch filter for a mid scoop a la Superfuzz, and an op amp output buffer. There is two versions for this (2019 and 2020) and since they differ quite a bit … Read more
Fuzzlord Effects Void Master
A variation of the old one knob fuzz. Note that a few cap values and the potentiometer value is unknown. First, power filter which suitable values should be 47uf or 100uf, I went with a 47uF in the layout. Second. BC filter cap for Q2 is unknown but my guess is 220pF. This can be … Read more
