An op amp emulator of Mesa Boogie Mark II C+ which was used by Metallica for Master of Puppets. There is also a an eq board (which is huge!) so that one is for another post. Schematic is avaiable HERE.
Nick Williams of Dunwich Amps take on the Buzzaround circuit. The most notable mods are the silicon transistors in the preamp section, a big muff tonestack with a recovery stage. Schematic can be downloaded HERE.
One more layout before x-mas… Here is a modified Boss DS-1 into a taeaked HM-2 EQ. Should sound pretty wild, eh? Schematic is avaiable HERE.
Here is a quite simple Booster/Eq/light OD circuit designed by Kurt Ballou. More info and schematic HERE.
There is two layouts of this one, one stock with one control. Since it begs for modifications I added a second layout with four pots for more control: 100K resistor at the output is replaced with a 100k volume control. 33k/68k before Q2 is part of a fixed Big Muff style tonestack so they are … Read more
