Marshall
MARSHALL: 1974X AKA the Marshall 18w one knob tone controls
Another simple one knob tone control, this time from the Marshall 18w amplifier, or the model 1974x, whatever you prefer… Marshall used two different tone controls in the amp. A lot of folks build the 18w lite, which is just the normal channel of the amp, and they often use the trem channel tone … Read more
Aion Fx Cerulian Amp Drive
This one have been requested a wef times during the last week… Schematic is avaiable HERE.
Marshall Shredmaster
Here’s another old layout redone for all you Jonny Greenwood fans. I think the old layout was based on an old and incorrect schematic (here’s the schematic used for this layout), but this one should be right and a much easier fit in an enclosure than the old one.
MARSHALL: Blues Driver / Boss Discrete Opamp
If you’ve read any recent posts, you may have noticed that I’m experimenting with discrete opamps – specifically replacing standard opamps with simplified discrete opamps – I’ve only played with the Joe Davisson diode compression opamp so far (with some success). While I was checking out DIY Stompboxes, I saw Rob Strand was experimenting with the Boss discrete opamp … Read more
MARSHALL: Blues Breaker, Discrete Opamp Mod
I’ve had some success with the Joe Davisson diode compression discrete opamp on some other circuits (namely the Cornish SS-2), so I thought I might try a Blues Breaker – it works… sounds good. Apart from the lack of IC, there are a couple of other minor mods to a stock Blues Breaker, mainly a larger input … Read more
MARSHALL: Shredmaster
The Marshall Shredmaster is a somewhat classic distortion, even if it has a cringe worthy name. I don’t think I would have even looked at this back in the day as a result of the name. Shredding is not my thing. I think it’s fair to say that Radiohead using the Shredmaster has certainly helped … Read more
MARSHALL: Blues Breaker
Nothing to see here – just a Marshall Blues Breaker… quite the classic today, bit did not do well when it was released. MARSHALL BLUES BREAKER – VERO LAYOUT
