This one was actually pretty easy to knock out after doing the G3. Slightly simpler and with less clipping than the G3, it’s got loads of gain on tap. This also has the same pot layout as the the G3, so just use that drill template.
You guys super pestered me to do this one, so here it is. Now get off my back! 😄 Layout turned out fairly big, but not overly so. It should fit nicely in a 1590BB.
Shares the same footprint as G4 pedal but some component values is tweaked for less gain and slightly different overall eq.
