This is (or was now I guess) one of the few Run Off Groove designs I haven’t laid out. It’s not a small circuit and I ended up laying it out for a 1590BB so the pots can be board mounted (but it will fit in a smaller enclosure if wire them off board). I … Read more
For Fuzz Friday here’s the Run Off Groove Whisker Biscuit–Big Muff meets Bazz Fuss. From the ROG site: The Whisker Biscuit is a hybrid of the Bazz Fuss and the Big Muff Pi. A single Bazz Fuss stage replaces the two clipping stages of the BMP. Smooth, super-long sustain, and good clean-up with the guitar volume knob … Read more
Continuing to knock out the last few ROG designs I haven’t laid out. This one’s a pretty easy little circuit, emulating the distortion in Rockman amps designed an used by Boston guitarist Tom Scholz. The toggle allows you to go between 80s (classic) and 90s (modern) tones, and it should all fit in a 1590a. … Read more
Still a few Run Off Groove designs I haven’t laid out yet, and this is one of them. It’s based around the 4049 IC chip and features 2 channels of amp-like distortion. I’ve laid it out to fit in a 125B with dual footswitches. Bias Q1 to 4.5v and then adjust to taste as usual. … Read more
Here’s Run Off Groove’s take on the Dr. Q by JD Sleep with mods and improvements suggested by Mark Hammer and Jack Orman. More info, schematic and sound clips here.
I know I’ve mentioned this to a few people over the past year probably, but I’ve finally been able to get it edited. That’s right, here’s my tutorial on how I layout circuits in DIYLC… the first installment at least. The tutorial shows how I created today’s layout–the Uno from Run Off Groove. It’s a … Read more
Not sure how/why I avoided laying this one out for so long. The Azabache is a great sounding overdrive that emulates classic Fender amps. Check out the ROG article on the circuit for more info, schematic and sound demos. Adjust the trimmers so there’s 6v on the drain of Q1, and 5v on the drains … Read more
Here’s a nice little boost from ROG that originated from trying to design a FET-based Rangemaster treble booster. I’ve laid it out for a 1590a with board mounted 9mm pots. More info, schematic and sound clips can be found here.
Got a request to do this one again but with board mounted pots. If you don’t know, it’s a FET emulation of the classic Supro 16T amp. More info, schematic and demos can be found on the Run Off Groove article.
The ROG Ginger is an amp emulator designed to sound like the classic Ampeg SB-12 Portaflex. So it’s intended for bass, but sounds good with a guitar as well. Schematic, sound clips, and more info can be found in the ROG article. It’s laid out for board mounted pots will fit easily in a 125B … Read more
