SRS: EQ Exciter, Creepy Fingers mod

13 Jun 202629 Feb 2024 by chords

CREEPY FINGERS SRS EQ vero layout v1 43d75d387e67

I was poking around in my files and realised that I had started a layout for this a couple of years ago, but had not quite finished it – anyways, here it is. It’s SRS EQ Exciter from the seventies, with the Creepy Fingers mod. If you want to make it stock, replace the Gain … Read more

SRS Eq Exciter w. gain ctrl

13 Jun 202614 Jun 2019 by chords

SRS EQ Exciter

13 Jun 202614 Jun 2019 by chords

Here’s a bit of a rare one for Fuzz Friday. It’s essentially a silicon Fuzz Face with an output buffer and a mid scoop tone control. Schematic and rundown of the original here. It should fit in a 1590a with 9mm pots board-mounted. I’ve also kept the pad (marked NC in the schematic) so if … Read more
