Exar OD-01 Overdrive
These things is getting really expensive especially since it got hyped by JHS and was included as the “XR” mode in their Bonsai pedal. It is basically a YATS/Boss-OD-1 with some value changes here and there and assymetrical soft clipping. Schematic is avaiable HERE.
Devi Ever/Dwarfcraft Devices Super Soda Meiser
This one was recently traced on FSB and as i have a soft spot for Devi & Dwarfcraft circuits alone and together, i had to draw it up.. A bit like original Soda Meiser, or at least some revisions of it, but this time with a Chaos switch and a Drone-knob.
Hawk II Tonal Expander
With some modern improvements: Onboard voltage doubler for 18v operation. Series inductor for the Bass control since stock value is impossible to source nowadays. Master volume control. Schematic is avaiable HERE.
Exar SF-02 Super Fuzz
Another Exar box traced by Vitali from Drunk Beaver pedals. I’ve been curious about this one for a while. It turns out that the fuzz section are a Boss DS-1 derivate. The interesting part lies in the Eq section. The Frequency pot controls both a Big Muff tonestack (with a very deep mid scoop notch) … Read more
Smart People Factory Red Threat V2
Happy holidays! We hope you have a good one! …and there’s number of unverified layouts for you to try out this holiday season! Like this one..
Dylan 159’s Blendy Buffoon
Next up from Dylan159’s Unreleased Circuits is the Blendy Buffoon. We’ve had a bunch of different blend/mix/loop designs up already, but this idea was still missing. Some may have stumbled upon an issue where you couldn’t use a basic blend circuit with the likes of Marshall Bluesbreaker or MXR Dynacomp. That issue is due to … Read more
