VFE Pedals
VFE Dragon
Here is a pretty cool overdrive with qquite a poweful eq section. However, it requires som fiddling to make your own custom 10kC/100kC dual gang pots for the EQ controls. HERE is a small tutorial at page 3. Second, the DPDT on/on/on switch type isn’t specified in the info sheet I have, only “the coomon … Read more
VFE Red Wolf
A Rat variant with some added features; a Fat control and a variable diode control called Comp.
VFE Choral Reef Analog Chorus
Great sounding chorus which is based on EHX Small Clone but with much more tweakability. Note that the swithing board is not included for this layout so the voltage reference components (8,2k, 10k and 47uF) istaken from the switching board into this layout. Schematic and info HERE
