Month: June 2018
Pete Cornish G2 – Vero / Tagboard Layout
Pete Cornish G2 – Vero Layout Pete Cornish G2 w/ Bypass Buffer & Wiring
Jon Patton Cardinal Tremolo V2
The Cardinal Trem is a harmonic tremolo designed by Jon Patton and meant to emulate the tremolo effect built into several Fender amps from the early 60s (Twin, Super, Pro, Showman, etc). What makes it harmonic? The audio signal is amplified by the first JFET stage, then split into a high-pass path and a low-pass … Read more
Optical Bypass
Here’s another alternative to the 3PDT for bypass wiring. It’s based on the method VooDoo Lab uses for bypass and uses a optocoupler to achieve true bypass using a DPDT. I’ve drawn up 2 different layouts for this: a standard perf/PCB layout, as well as another PCB I did in Eagle with the footswitch board … Read more
Baja Ampeg SVT Bass Amplifier
Original FSB thread and schematic available here. I’ve put the Mid Freq switch components on a separate board to make it easier to box it.
EarthQuaker Devices Dirt Transmitter
To close out EarthQuaker week, here’s the Dirt Transmitter. I traced this one myself and below is a video showing the process. It’s similar to a Fuzz Face, but a little different. I found this description from (I’m assuming) Jamie over on TGP: I guess it’s kinda like a fuzz face but it started as … Read more
EarthQuaker Devices Dunes
If the Palisades is too much for you, the Dunes has a much smaller footprint and less controls to get distracted with. Pretty standard Tube Screamer clone with clipping options and a couple tone shaping switches. Might be a bit of a squeeze but it will fit in a 1590B with board mounted pots.
