Black Arts
Black Arts Toneworks Quantum Mystic
Quad op amp version per as the original. …and a 2x dual op amp version. For some reason it has some minor noise issues with the Mid and Volume controls cranked.
Black Arts Toneworks Revelation
For Fuzz Friday here’s the Revelation from Black Arts Toneworks. There are 2 versions of the Revelation: the Super Bass and Super Lead. The Super Bass is a stripped down Pharoah without the tone control, no clipping diodes in the 2nd gain stage, and an input gain control. The Super Lead version is the same … Read more
Black Arts Toneworks Revelation Super Lead
From the source: A revelation. Stripped down all out amp pusher. The Revelation has a trio of controls. Pre Gain, Gain, and Volume. LOTS of volume. Pre Gain sets the overall gain level of the device, the gain control dials in the correct amount of distortion and the volume knob absolutely slays the front end … Read more
Black Arts Toneworks Oath
Essentially the oath is the Black Arts Revelation Superbass without any knobs. After VisualFuzz found an image of the Oaths board, and having to enhancing it to see the resistor values without the image being distorted I’m pretty certain that I’ve got the values and placements for the resistors to replace the pots. ‘
Black Arts Toneworks Black Forest
This is Black Arts’ take on the Colorsound Overdriver. There are a few component value changes and 6 different caps on a 2 pole, 6 position rotary switch at the input. It’s got a wide range of tones, and goes from boost to overdrive to fuzz. It’s laid out for board mounted pots and would … Read more
Black Arts Toneworks Revelation Super Bass
Direct from the source: A revelation. Stripped down all out amp pusher. The Revelation has a trio of controls. Pre Gain, Gain, and Volume. LOTS of volume. Pre Gain sets the overall gain level of the device, the gain control dials in the correct amount of distortion and the volume knob absolutely slays the front … Read more
Black Arts Toneworks Fnord
Got a little Eagle excursion for Fuzz Friday. Here’s the Fnord from Black Arts Toneworks. It’s pretty much the same as the Escobedo Digital Octaver Fuzz with an added diode lift switch (though that’s jumpered in the originals). It’s a pretty gnarly fuzz with a wide range of tones. For you perfboard builders you should … Read more
Black Arts Toneworks Black Sheep
A biker fuzz if ever there was one. This week’s Fuzz Friday layout is the Black Sheep from Black Arts Toneworks. It’s great on both guitar and bass and features 3 stacked gain stages with a 4 position switch dictating the input capacitor. Here’s the schematic for reference.
