Octave
Death by Audio Absolute Destruction
A transatralntic trace by Enrico, AlexS and fuzzhead. A big thanks goes to Enrico for letting us trace his pedal, all the images and the schematic. The layout is tested and verified. There is some odd parts in there which can easily be subbed for other values. (221ohm to 220 ohm and 4,64k to 4,7k). … Read more
Ibanez No. 58 Standard Wau Fuzz – Fuzz section
Similar to the Ibanez No 59 Standard Fuzz but with a different tone section and a few extra resistors. If you want a bit more overall output level, 47k resistor connecting to Balance 3 could be can be replaced with a small value or a jumper. Another useful mod is to sub the germanium diodes … Read more
Ace Tone FM-2 Fuzzmaster Stock
I had a request for a stock Ace Tone FM-2 Fuzzmaster and realized I only had a quite heavily modified circuit in the library. So here it is Alex!
Earthquaker Devices Hoof Reaper
With an added mod from Fuzzdog which took the octave control from EQD Life Pedal so you can dial in the amount of octave up as you desire. Schematic and info HERE
Death by Audio White Card Fuzz
Now verified. But as with DBA Octave Clang I felt it was lacking in gain. But there is a super simple mod to increase the gain of the LM386 amp. Just omit the cut between pin 1 and pin 8. Now we have both a fat fuzz or way over the top octave fuzz with … Read more
