Happy Fuzz Friday everyone! Got a request for this one put forth on FSB. It’s based on the ThroBak sTone Bender, which itself is just a straight clone of the Tone Bender Mk II Professional. The layout is setup for positive ground and PNP transistors. You can use a voltage inverter daughter board or flip any polarized … Read more
From the Source: The Strange Master treble booster now includes both Germanium and Silicon transistors. These transistors are switchable so the user can now get classic Dallas Rangemaster treble booster Germanium tones and higher gain Silicon treble booster tones from one pedal! ThroBak guitar effects pedals offers another classic Signature Sound effect with the Strange … Read more
Essentially a Rangemaster with a switch selecting the input cap (Hi/Lo) and another switch (Ge/Si) selecting between a germanium or silicon transistor. The bias pot helps to fine tune the bias (imagine that lol) differences between germanium and silicon modes. Other transistors can be used other than what’s specified. Something in the 100-120 hFE range … Read more
Pretty much a Colorsound Overdriver clone. Laid this out for a 125B (because of the dual footswitches) with board mounted pots. The boost footswitch bypasses the PreGain pot and only uses one side of a DPDT. Use the other side for LED wiring. If the off board wiring is confusing, check out the thread with … Read more
