Unverified
Dylan159’s Troupple Boost
I’ll be posting a few circuits from Dylan159’s Unreleased Ciruits. There was the Fuzz Facelift posted earlier and i’ll continue with more of these goodies. Next up: Troupple boost. Gamers might get the reference. This came out from my wish for a simple, clean treble boost that could work from a variety of supply voltages … Read more
Boss OD-2r Turbo Overdrive – Turbo channel
Schematic and more info about this circuit is avaiable HERE.
Boss OD-1 – Dual Op Amp version
Forgot I had the later and more common version in a folder… For the earlier quad op amp version there is a layout HERE.
Vesta Fire / Reagun / Nadine’s Overdrive
Second post for today is the Overdrive from Manfred’s trace (at FSB). This comes from the same series as it’s distortion brother (see the earlier Vesta Fire Distortion post), but the design is slightly more obscure. Still, the inverting input filter path to ground gain pot method on a non-inverting gain stage is used. However, … Read more
Vesta Fire / Reagun / Nadine’s Distortion
Not that long ago, Manfred traced his Reagun Distortion unit and posted the results on FSB. These pedals were sold as Vesta Fire, Nadine’s and Reagun brands around early to mid-eighties. All these were made by Shiino Vesta Fire Corporation (SVFC), which became Vestax back in 1987. Designwise these are not bad at all. This … Read more
Exar MM-04 Moon Metal
Next up from Vitalii’s traces is Moon Metal from later Exar series. Youtube demo found isn’t all that great, but there’s very nice EQ section and gain range seems quite good as well. Not a small circuit, but i think this could be quite usable.
