Another weird one! A rotary selector selects between a four stage phaser, wah and phaser and wah combined. The latter mode is supposed to be something out of this world. Deadend Fx (who else) have a projects for this beast and as usual, don’t hesitate to support these guys by bying some nifty PCBs. They … Read more
An old, obscure, weird fuzz/wah/filter/noise/volume pedal from Japan dated from the the early 70s. Schematics and more info HERE. Note that a couple of resistor values was is incorrect in the original schematic but it has been corrected for the layout below.
This one was quite a nightmare to draw so I’ve attached the schematic for anyone who is willing to take a second look.o.O
Another great tracing (and de gooping) work by Tobias. This one is supoosed to be a heavier version of a Colorsound Overdriver with an added “Contour” diode control for more fuzz on tap.
Another trace by Tobias. This one is based on ROG Whisker Biscuit but with larger input, coupling and Miller caps. Also, the tonestack has been modified for a wider range.
An old russian Boss MT-2 derivate. The eq section and the general topology is pretty close to the original. But cap and resistor values differs quite a lot in most places and the gain control looks like it is borrowed from a Boss DS1.
Per request. A DIY project posted by Dylan159 at FSB a while back. It is based on Bajaman’s EVH OD but tweaked and simplified. Schematic and more info HERE.
