I saw a post today about leakage and temperature, so I thought I’d do a quick test myself to see how close it came. The test distinctly lacked scientific conditions – for starters I wasn’t even wearing a white coat at the time, but the results seem to match the theory. For germanium transistors, leakage … Read more
The SonicVI silicon MKI Tone Bender is firmly based on the original, with a few additions and some minor changes. Being silicon based, the transistors do not self-bias, so additional resistors have been added from V- to the base of Q1 & Q3. The transistors used are early Mullard PNP silicon OC202 which are quite … Read more
Schematic is avaiable HERE. Note thjat the Deadend mods that are includued in the schematic are omitted for the layout octave trimpot, starve jumper…).
Another contribution from Chris at CDC Fx! This layout is already VERIFIED and good to go. Schematic is avaiable HERE and as you can see the drive section is a modified MXR Distortion+ derivate. You can yeasily tweak it to DOD 250 or countless other variations of the circuit.
A short guide to off-board wiring for positive ground effects. It’s not as complicated as it’s sometimes made out, but I do get that it’s confusing. If you want all the details, head over to the tech section of Amplified Parts – it may hurt your brain by the end, as it’s very detailed. Note #1: … Read more
I’ve had a few questions lately via Instagram about some basics on my vero layouts – while this doesn’t cover everything, I hope it helps clarify a few things for people just starting out. Essentially, my vero layouts are functionally the same as many others, the key differences being the use of colour coding, and … Read more
Since I’ve been on a slight Beatles related run lately, I thought I should tackle the Castledine Electronics Magical Mystery Box. This is Stu Casteldine’s version of the Brilliant channel from a Vox Conqueror guitar amp. Castledine included a gain recovery section at the end and the transistor-based distortion switching has been removed. I ran … Read more
