Mixer
Opamp 3 channel splitter/mixer ON HOLD
Updated 6th February 2014 I have a TC Electronic G-Force and Eventide Eclipse in the parallel effects loop of my amp and use a rack mixer to keep them in parallel with each other, and so allow me to use them both 100% wet and so avoid having to digitize my dry signal. I do … Read more
4 Channel Mixer
First i thought i’d just post this after the 2 channel version to the same post – but the permalink to that post is “2-channel-mixer”. So. Sorry for “double” post, but here’s one for NoNE. Here’s the revised version with more gain/level from the mixer opamp. I’ll revise the 2 channel version too…
2 Channel Mixer
I needed something like this myself, so why not share. I’ve been thinking about building a console for our keyboardist. She has this amazing wooden 70’s Casiotone that i dugged up from trash and it worked. It’s default sounds are pretty bad, but using the organ sound and putting it through Skreddy Lunar Module Deluxe … Read more
Split ‘n’ Blend
I like these little “utility boxes” (Please take note! This circuit will not work as a blend for pedals that invert the signal polarity (or phase). For a few examples of such pedals; the likes of Dyna Compressor/Ross Comp and their derivatives and Marshall Bluesbreaker among others. The symptom of inverted signal polarity (phase) will … Read more
Mini JFET Blend
A simple mini blend layout based on Sean’s JFET schematic here: http://seanm.ca/stomp/minblend.html Will easily fit in a 1590A box and I probably wouldn’t even use a stomp switch with this because in the unblended position of the pot, this will essentially be just a JFET buffer. You could always add a mini toggle to bypass … Read more
JFET Parallel Looper
This is one of those versatile builds that could be useful for a number of different tasks. Effects and dry signal in parallel, 3 channel splitter/mixer, 1 input 3 outputs for using multiple amps, 3 inputs into one output to use multiple instruments, convert serial effects loop into parallel … and so on. I made … Read more
Guitar and Bass Paralooper
From Moosapotamus: The ParaLooper is something every effects-using Bass player should have, because it will ‘Bassify’ any bottom sucking, high-passing guitar pedal out there. And, it’s pretty simple to build, too. Instead of just an effect loop pedal, this is actually a little mixer that blends your straight signal with whatever effect (or chain of … Read more
