Just a little reference to Soviet-era transistor pinouts. SOVIET TRANSISTOR PINOUTS note: in addition to potentially different pinouts, some Soviet-era transistors can have the case connected to the base – which is not good if it touches anything else. The dot on the case usually marks the emitter, not the collector as often found on European … Read more
COMMON SILICON TRANSISTOR PINOUTS TRANSISTOR NUMBERING SYSTEMS JEDEC (JOINT ELECTRON DEVICE ENGINEERING COUNCIL) example: 2N2222 First Number 1 = Diode 2 = Bipolar transistor or single gate field effect transistor 3 = Dual gate field effect transistor Second Letter = N Subsequent numerals = Serial number Important to note that there is no correlation between … Read more
SINGLE OPERATIONAL AMPLIFIERS PINOUTS LM386 TL061, TL071, LM741 DUAL OPERATIONAL AMPLIFIERS PINOUT TL072, 4558, 5532, LM358, LM833 QUAD OPERATIONAL AMPLIFIERS PINOUT TL074 DUAL OPERATIONAL TRANSCONDUCTANCE AMPLIFIERS PINOUT LM13700 SINGLE OPERATIONAL TRANSCONDUCTANCE AMPLIFIER CA3080 PINOUT note: out of production, LM13700 is the current equivalent CA3080 HEX INVERTING BUFFER PINOUT – CD4049UBE
