Fuzz
PedalPCB / Chuck D. Bones Spunk-O-Matic
How about a MOSFET/Germanium Harmonic Percolator with some extra controls? And silicon/infrared diode clipping? Chuck D. Bones Spunk-O-Matic has it all… Schematic is avaiable HERE.
Death by Audio Black Card Fuzz Delay
Once again, Ian Sheridan sent me another one of those DBA business card circuits to trace.
Ace Tone FM-2 Fuzzmaster V2
Bernarddur, the schematic and tracing wizard over at FSB got hands on a FM-2 a while ago. It turns out that the circuit went through some revisions during its short lifespan. The Fuzz Adjust (Tone) control had been reowrked and the recovery stage had been altered. Since it is one of my favorite vintage circuits … Read more
