Fuzzlord Effects Riff Master
Another trace by evilarsen. This is basically a Rangemaster tuned for more low end..
Booster
Hawk II Tonal Expander
With some modern improvements: Onboard voltage doubler for 18v operation. Series inductor for the Bass control since stock value is impossible to source nowadays. Master volume control. Schematic is avaiable HERE.
Mad Professor Ruby Red Booster
For now, only the booster/overdrive section, might add a separate board for the switchcable bypass buffer later on… 2N5952s is getting really scarce but 2N5457s or 2N5458s is usually a good sub. Just mind the orientation! Schematic is avaiable HERE.
